Synology

Synology RS18016xs+

Skip image gallery
Synology RS18016xs+
Synology RS18016xs+
Synology RS18016xs+
Synology RS18016xs+
Synology RS18016xs+
  • Scale up to 180 drives with 14 Synology RX1216sas
  • SAS & SATA III 6Gb/s interface support
  • Performance boost by SSD Cache Technology
  • Data protection by advanced snapshot technology & built-in data integrity check

This product is no longer available.

Synology RS18016xs+
  • Scale up to 180 drives with 14 Synology RX1216sas
  • SAS & SATA III 6Gb/s interface support
  • Performance boost by SSD Cache Technology
  • Data protection by advanced snapshot technology & built-in data integrity check

truebase-theme.detail.tabsDescription

RackStation RS18016xs+
Synology RackStation RS18016xs+ provides the reliable, superior-performance network attached storage solution for enterprises seeking uninterrupted service with comprehensive business applications. Scalable up to 1,440TB, Synology RackStation RS18016xs+ simplifies data management, optimizes virtualization environments, and rapidly expands storage capacity with minimal time investment in setup and maintenance. Synology RS18016xs+ is backed with Synology’s 5-year limited warranty.

Blazing Performance
RS18016xs+ delivers blazing performance at over 3,900 MB/s throughput and 348,000 IOPS under RAID 5 configuration with VLAN1. Through advanced flash technology, the combination of hard drives and read/write-optimized SSD cache boosts throughput efficiently while minimizing cost per gigabyte. In addition, RS18016xs+ comes with native SAS and SATA III 6Gb/s support that unleashes the full potential of blazing fast SSDs, ensuring the optimum data process under heavy system loading.

In addition to default 4 Gigabit ports, RS18016xs+ comes with two PCIe 3.0 x8 slots, allowing installation of two dual-port 10GbE Network Interface Cards (NIC)3 for maximized bandwidth, bringing you the superior performance that data-intensive applications demand of your storage system.

Equipped with 8GB RAM and up to 32GB ECC RAM expansion support, RS18016xs+ ensures data accuracy as well as superior performance to provide a rigorous foundation for the mission-critical tasks of your business.

[[more]]Btrfs: Next Generation Storage Efficiency
RS18016xs+ introduces the Btrfs file system, bringing the most advanced storage technologies to meet the management needs of modern large scale businesses:

●             Built-in data integrity check detects data and file system corruption with data and meta-data checksums and improve overall stability.

●             Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders.

●             Advanced snapshot technology with customizable backup schedule allows up to 256 copies of shared folder backups without occupying huge storage capacity and system resources.

●             File or folder level data restoration brings huge convenience and saves time for users who wish to restore only the specific single file or folder.

●             Cloud Station with file versioning reduces down to half of storage consumption when compared with Ext4 file system.

Virtualization Certified
RS18016xs+ provides seamless storage solutions for virtualization environments, including VMware, Citrix, and Hyper-V. With VMware vSphere 5 and VAAI integration certified, RS18016xs+ helps offload specific storage operations and optimizes computation power for unparalleled performance and efficiency in VMware environments. As the centralized storage of a virtual environment, RS18016xs+ enables virtual machine migration, allowing transition from server to server whilst eliminating service downtime and disruption to user. Windows Offloaded Data Transfer (ODX) and Synology Advanced LUN support extremely improves the efficiency on massive data transfer and migration.

Comprehensive Business Applications
Powered by the innovative Synology DiskStation Manager (DSM), RS18016xs+ comes fullyequipped with applications and features designed specifically for large-scale business:

●             Easy integration with existing business network environments through Windows® AD and LDAP directory services without recreating user accounts.

●             Windows ACL support provides fine-grained access control and efficient privilege settings, allowing RS18016xs+ to fit seamlessly into current infrastructure.

●             Built-in backup applications protect information assets by regularly backing up files and iSCSI LUNs locally and remotely.

Robust Scalability
With 12 HDD trays and up to 1,440TB of total storage capacity2, RS18016xs+ is designed to grow with businesses. RS18016xs+ supports up to 180 HDDs or SSDs for flexible capacity and balanced performance to meet the needs of varying applications and processes. When the storage capacity of RS18016xs+ nears it limit, expansion is easily accomplished with Synology RX1216sas via specially-designed connection cables to maximize data transmission throughput between main server and expansion units.

Management of the large storage space on RS18016xs+ is simple and flexible. Multiple Volumes on RAID allows users to create more than one volume on a RAID structure, providing a flexible and efficient way to manage the storage across all hard drives. When the need for more space arises, the volume could be easily expanded without any service disruption.

Reliability, Availability & Disaster Recovery
System reliability is of paramount importance to businesses which depend upon their commercial servers every day. RS18016xs+ responds to these concerns with wide-ranging availability and redundancy features:

●             Synology High Availability ensures seamless transition between clustered servers in the event of server failure with minimal impact to applications.

●             Redundant data paths, power supplies, system fans, and network ports with failover support ensure continual service uptime.

●             High reliability system design including fan-less CPU heat-sink and passive cooling technology prevents single point of failure.

●             ECC RAM modules detect and correct errors during data transmission.

●             Tool-free system fan design allows hot swap and easy exchange of malfunctioned system fans. With the brand-new screwless rail kit sliding: Synology RKS1314 (optional), system installation and maintenance is fast and easy.

Specifications
Resumed specifications
