QNAP TVS-h1688X-W1250-32G
- Intel Xeon W-1250 6-core 3.3 GHz processor (boost up to 4.7 GHz)
- 12 x 3.5-inch SATA 6Gb/s, 3Gb/s + 4 x 2.5-inch SATA 6Gb/s, 3Gb/s
- Memory 32GB ECC UDIMM DDR4 (2 x 16 GB)
- High-speed media collaboration over 10GbE virtual machine applications
€3,394.20 excl. BTW
delivery time: contact us
12 days or more
- Intel Xeon W-1250 6-core 3.3 GHz processor (boost up to 4.7 GHz)
- 12 x 3.5-inch SATA 6Gb/s, 3Gb/s + 4 x 2.5-inch SATA 6Gb/s, 3Gb/s
- Memory 32GB ECC UDIMM DDR4 (2 x 16 GB)
- High-speed media collaboration over 10GbE virtual machine applications
Productinformatie
The high-capacity TVS-h1688X features a powerful Intel Xeon W processor and allows for installing two QNAP QXP-T32P Thunderbolt™ 3 PCIe expansion cards (sold separately) to attain four Thunderbolt 3 ports, making it a perfect match for Thunderbolt-equipped Mac and Windows users for high-speed media collaboration. The built-in 10GbE and 2.5GbE connectivity supports Port Trunking and failover to further satisfy bandwidth and reliability demanding business applications. Running the ZFS-based QuTS hero operating system, the TVS-h1688X supports block-level inline data deduplication and compression, near-limitless snapshots, real-time SnapSync, and read/write cache technologies, helping your business achieve reliable service-level agreement performance, from creative workflows to file server, virtualization server, and efficient file backup and recovery applications.
- Attain quad-port Thunderbolt 3 connectivity by installing two QXP-T32P expansion cards in the PCIe Gen 3 x4 slots.
- Note: QXP-T32P expansion cards are sold separately
- Two 10GBASE-T and four 2.5GbE LAN ports accelerate virtualization, intensive file access, large backup/restoration tasks, and media transfer.
- PCIe slots allow for installing 5/10/25/40GbE adapters, QM2 cards, or graphics cards to increase application performance.
- 4K media playback and real-time transcoding; directly output videos to an HDMI display (up to 4K @30Hz).
- Supports virtual machines and containerized apps, centralized storage, backup, sharing, disaster recovery, and storage expansion.
- Cloud storage gateways realize hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency data access to the cloud.
Specifications
- Capacity: Add drives yourself
- Encryption: Hardware based
- External interface: 3 x PCIe
- Extra's: HDMI output
- Interface: M.2 SATA
- LAN: 1 x 2.5GbE/1GbE port, 4 x 5GbE/2.5GbE/1GbE port
- Nr. of 3,5" HDD bays: 12
- RAID: Hot spare
- RAM: 32 GB ECC UDIMM DDR4 (2 x 16 GB)
- Redundant power supply: No
- Type: Tower
- SKU: TVS-h1688X-W1250-32G
- EAN: 4713213518403
Dimensions and weight
- Length: 303.7
- Height: 324.1
- Width: 369.6
- Weight: 16.3
